T Slot C Beam
Posted : admin On 4/6/2022Product Description
When using our custom T-slotted aluminum extrusions, you simply insert a T-nut and fastener into the extrusion and tighten it to create a durable, strong and lightweight structure that is both functional and attractive. PDTech T-slot Vslot frame PDTech 20mm x 20mm 2020 series aluminum extrusion - up to 6 feet (1.82 meters) long - custom cut (751mm-1000mm) 5.0 out of 5 stars 7 Boeray 10pcs Aluminum Alloy T Slot L Shape Joining Plate and 50pcs M5x8 Hex Screw and 50pcs T Nut for 2020 Series Aluminum Profile. Custom cut V-Slot, T-Slot aluminum extrusions & related accessories like T nuts, brackets etc infuse life into frame designs, linear motion projects, 3d printers, desktop router machines & much more. Being makers ourselves, we take pride in saying that all components on our store have been thoroughly used & tested by us.
Details
Profile dimensions: 40x80mm
Profile type: V-SLOT
Slot width: 6mm
Slot depth: 6mm
Material: 6060-T5 Aluminium Alloy
Surface treatment: Black/Natural Anodization
Cutting service (see 'Custom Size Cut' option for non-standard lengths)
Length Tolerance: ± 0.25mm
Tapping
Tap size: M5
All C-Beam Profiles come pre-tapped on 4 of the 6 core holes, ready to accept C-Beam End Mounts
Other dimensions: see product photos
Additional specifications: Spec Sheet
C-Beam is a profile based on the popular V-Slot linear guide system. It incorporates a C shape profile which gives added strength and functionality.
C-Beam Linear Rail® is considered to be a 40mm x 80mm profile which is compatible with all V-Slot Parts and Accessories.
It's precise, easy to work with and allows you unlimited design control through it's modular nature.
What is OpenBuilds C-Beam?
Since C-Beam is a product of the V-Slot line all standard V-Slot parts and accessories are compatible! Of course, like V-Slot, every side of C-Beam can be used a linear guide.
What Can Be Made Using OpenBuilds C-Beam?
You will find that C-Beam is the perfect solution for most projects. Below is a list of a few ideas to get you started.
3D Printers
CNC Engravers
Hot Wire Machines
Laser Cutters
Camera Sliders
Plasma Cutters
Robotics
Furniture
& Much, Much More!
OpenBuilds Part CAD Models and Drawings
Reviews
Write Your Own Review
Only registered users can write reviews. Please, log in or register
Product Tags
C-Beam™ Linear Rail
The newest profile from the OpenBuilds' Team
- C-Beam is a profile based on the popular V-Slot linear guide system. It incorporates a C shape profile which gives added strength and functionality.
- Since C-Beam is a product of the V-Slot line all standard V-Slot parts and accessories are compatible! Of course, like V-Slot, every side of C-Beam can be used a linear guide.
- C-Beam is available in multiple lengths and comes with 4 of the holes pre-tapped and ready to accept C-Beam end mounts. This allows you to quickly create C-Beam linear actuators. Use a M5 Threaded Drill/Tap, if needed to easily tap the remaining holes, or if you need to cut the C-Beam to a custom length.
- You can add multiple plates for added precision and strength.
- You can use any of the V-Slot gantry plates with C-Beam.
- You can even 3D Print your own parts to produce customized creations.
- C-Beam is extremely modular which allows for practically unlimited mounting possibilities and build configurations
OpenBuilds C-Beam is made with 6063 T-5 Aluminum and it has a beautiful, shiny, super smooth, clear finish. The finish is much shinier than standard profiles which allows for a smoother ride for the OpenBuilds V Wheels.
C-Beam Linear Rail is considered to be a 40mm x 80mm profile which is compatible with all V-Slot Parts and Accessories.
C-Beam Weights:
250mm 1 lb. 2 oz.
500mm 2 lbs. 4 oz.
1000mm 4 lbs. 4 oz.
